    Honeywell BW Icon – 4-Gas Detector with Fixed 2-Year Life and Icon-Based Display

    Honeywell BW Icon is a 4-gas detector with a fixed 2-year life, no sensor/battery replacements, and icon-based alerts for easy use and fast safety decisions.

    Add to Quote
    Facebook
    Twitter
    LinkedIn
    Pinterest

    Description

    BW Icon

    Fixed-Life 4-Gas Monitor with Simplified Safety Alerts

    The Honeywell BW Icon is the industry’s first 4-gas detector with an icon-based display—designed to simplify gas safety monitoring for all workers, from experienced technicians to new contractors. This fixed-life monitor runs continuously for two full years with no battery or sensor replacements required, making it the most convenient and cost-effective solution for everyday gas detection.

    The BW Icon continuously monitors oxygen (O₂), hydrogen sulfide (H₂S), combustible gases (LEL), and either carbon monoxide (CO) or sulfur dioxide (SO₂), depending on your configuration. Instead of numerical gas readings, the device uses simple visual icons to show operational status and trigger alerts—reducing training time and eliminating confusion in the field.

    If danger is present, a bell icon and sensor-specific indicator light up clearly on the screen, prompting workers to respond immediately. With no hidden maintenance costs, this is the easiest and most efficient way to deploy multi-gas protection across your workforce.

    Features

    • No service required, activate and use for two years

    • Bluetooth included for ease of downloading and sending reports via the Safety Suite App.

    • One-button operation.

    • The latest in low power LEL infrared technology, giving you a battery runtime of 2 months.

    • 1-series sensor technology giving you wider temperature working conditions and a 5-year expected life.

    RELIABLE

    Two months of battery runtime on
    a 4.5-hour charge — and up to four
    months if you turn off the detector
    at the end of each shift. No daily
    charging, no unexpected downtime.


    EASY TO MANAGE

    The IntelliFlash™ green light indicates
    when the detector is in compliance
    and the amber light indicates the
    need for maintenance.

    COMPATIBLE

    The Honeywell BW Icon is
    compatible with the IntelliDoX
    instrument management system and
    Honeywell Safety Suite and also with
    TouchConnect™ using Bluetooth® for
    wireless configuration.


    RESPONSIVE

    sensors respond to
    dangerous gas levels in seconds,
    even in harsh temperatures.

    ACCURATE

    Low-power infrared LEL sensor
    is immune to silicone poisoning,
    which means accurate monitoring of
    combustibles.


    Specifications

    Specifications

    Minimum Temperature
    40 degrees celsius
    Gas Type
    H2S, CO, O2, LEL, SO2
    Certifications – Hazloc
    ATEX, IECEX, CSA
    Battery Run Time
    Up to 2 Months
    Ingress Protection
    IP66/68
    Wireless Technology
    BLE
    Alarm Type
    Audible, Visual, Vibrating

    Maximum Temperature
    60 degree Celsius
    Datalogging
    45 days of data at 15 sec interval, 8hrs/day
    Operating Life
    2 Years
    Humidity Range
    0%-95% RH
    Instrument Size
    108.2mm x 61.5mm x 43.2mm
    4.29in x 2.44in x 1.7in with Alligator Clip
    Warranty
    2 Years
    Weight
    185 grams

    Sensor Specifications

    Sensor Range Resolution
    CO 0-2000 ppm 1 ppm
    H2S 0-200 ppm 0.1 ppm
    SO2 0-150 ppm 0.1 ppm
    O2 0-30% VOL 0.1% VOL
    NDIR-CH4 0.100% LEL 1% LEL

    Resources

    Icon Datasheet

    BW Flex Manual

    Media

    Introducing the BW Icon from Honeywell
