    Thermo Scientific RadEye SPRD-GN – Compact Gamma-Neutron Radiation Detector with RIID Capabilities

    The RadEye SPRD-GN from Thermo Scientific is the first compact PRD to exceed ANSI N42-48 neutron standards. This pocket-sized detector delivers reliable gamma IDs and advanced neutron detection using CLYC and pulse shape discrimination (PSD) for unmatched dual-radiation performance.

    Add to Quote
    Facebook
    Twitter
    LinkedIn
    Pinterest

    Description

    RadEye SPRD-GN

    Thermo Scientific

    The Thermo Scientific RadEye SPRD-GN is a next-generation, compact spectroscopic personal radiation detector (SPRD) that delivers RIID-level gamma identification and advanced neutron detection in a pager-sized form factor. Engineered for frontline deployment, it significantly exceeds the ANSI N42.48 2008 standards for neutron alarms—making it ideal for homeland security, customs, border patrol, and nuclear facility personnel.

    At the heart of the SPRD-GN is a sophisticated Cs₂LiYCl₆:Ce (CLYC) detector, which is both gamma- and neutron-sensitive, eliminating the need for separate, bulky neutron tubes like He-3 counters. This single-detector design enables true dual-radiation performance in a highly portable device.

    The unit uses Pulse Shape Discrimination (PSD) to clearly distinguish between neutron and gamma radiation, allowing for highly sensitive and specific alarm thresholds. Additionally, its real-time spectrum monitoring incorporates a cosmic background neutron peak to maintain source-less stabilization, even in environments like open water with no natural radioactivity.

    Features

    • Can be worn in holster or standard service belt

    • Small and lightweight

    • Long battery life

    • Drop resistant to 1.5m

    • Can be operated in extreme temperatures

    Natural background rejection scenario

    Driving through tunnels, under bridges and past buildings with natural stone and past an artificial source.


    Great Download Spectra

    Single step download and viewing of spectra using included software and ANSI N42 – 2012 compliant file for local review and reachback


    Reducing Nuisance Alarms

    Reduce false alarms and better detect low level of artificial radiation such as hidden or shielded sources


    Specifications

    Radiation Detected
    Gamma and Neutron
    Detector
    CLYC (Cs2LiYCl6)
    Energy Resolution (662 keV)
    7.0%
    Sensitivity (cps per μSv/h) (662 keV)
    110
    NBR (Natural Background Rejection)
    Advanced with 6 energy windows
    Alarm Notification
    Display, LED, Sounder, Vibe
    Dose Rate Range
    1 μR/h – 25mR/h (10 nSv/h – 250 μSv/h)
    Energy Range (+/- 30%)
    60keV – 3 MeV
    Typical ID Time @ 1μSv/h (100μR/h)
    ~ 5 minutes
    Gain Stabilization
    Patent pending continuous source-less stabilization
    Neutron Verification
    thermal neutrons & fast neutrons
    Neutron Alarm Response
    <2 sec vs. ANSI N42.48 2008
    1 sec vs. ANSI N42.32 2016
    Thermal Neutron Sensitivity (cps/nv)
    4
    Designed to Meet Specification
    ANSI N42.48 2008
    Battery Type
    AAA x2
    Estimated Battery Life
    ~ 120 hrs
    Weight including Batteries and Rubber Sleeve (g)
    175
    Water/Dust Rating
    IP65
    Dropt Distance onto Concrete
    1.5m
    Wireless Communication
    BT4 optional
    Wired Communication
    USB to IR

    Resources

    SPRD-GN DataSheet
