Description

NEO Photo-ionization Detectors

Advanced Handheld VOC Monitoring

The NEO Series by mPower Electronics represents one of the most advanced families of handheld VOC (Volatile Organic Compound) detectors, offering ultra-sensitive ppb-level detection and high-range models up to 15,000 ppm. Designed for industrial professionals, first responders, and environmental teams, the NEO uses innovative photo-ionization detection (PID) technology paired with a high-performance UV lamp to ensure outstanding sensitivity, accuracy, and reliability.

VOCs include chemicals like benzene, alcohols, fuels, paint thinners, and solvents, all of which may pose significant health risks. Accurate VOC monitoring is essential across industries such as oil & gas, fire & hazmat response, pharmaceutical manufacturing, paints & adhesives, and more. Whether detecting trace-level VOCs or monitoring hazardous leak events, the NEO PID VOC Detector provides unmatched performance, reliability, and flexibility in the field.

Features

NEO Photo-ionization Detectors

Product Features

Smaller and lighter weight than comparable PIDs
Most stable ppb-level PID on the market
Outstanding linearity over full measurement range
Easy charging on laptop or other USB port
USB Micro Charger; combination USB-m charging and communications cable
Powerful battery (run time 24 hours)

Bluetooth Low Energy (BLE) connectivity standard
Search Mode for LDAR Sampling
Filter tube version for benzene- or butadiene-selective measurements
Large backlight graphic display
Lamp glow indicator
Rugged, stainless-steel housing with rubber outer boot

Specifications

Device Specifications

Size	9.06 x 3.15 x 2.36 in (230 x 80 x 60 mm)
Weight	24.69 oz (700 g)
Sensor	Photo-ionization sensor with standard 10.6 eV lamp (9.8 eV lamp in MP186 NEO BENZ)
Response Time t90	3 seconds for VOCs 45 seconds with Benzene filtering tubes
Accuracy	±3% (at calibration point)
Battery / Run Time	Rechargeable Lithium-Ion battery with 24 hours typical operation
Keypad	4 operation keys
Sampling pump	Built-in pump @ 450 cc/min, settable to low flow of 250 cc/min Sample from up to 150 ft (45 m) horizontally or vertically
Display	128 x 128 graphical LCD, 1.77 x 1.73 in (45 x 44 mm), with LED backlight for enhanced display readability
Direct Readout	Real-time reading of gas concentration (ppb, ppm, mg/m3, μg/m3) PID measurement gas and correction factor, lamp on/off, Man-Down alarm on/ off, battery status, pump status, datalogging on/off, wireless on/off, temperature and time
Alarm	Audible (90 dB @ 30 cm), visual (flashing bright red LEDs), and on-screen indication of alarm conditions plus wireless remote alarm notification High, Low, STEL, TWA alarms Over range alarm, battery low alarm Man-Down alarm with pre-alarm and real-time remote wireless notification
EMI/RFI	Highly resistant to EMI/RFI Compliant with EMC Directive 89/336/EEC
IP Rating	P-66/67
Datalogging	Standard 12 months at one-minute intervals Storage interval: 1 to 3,600 seconds (adjustable)
Calibration	Two/three-point calibration
Charging and Communication	Charging, data download, instrument setup and firmware upgrades on PC or laptop via Micro USB Wireless data and alarm status transmission via built-in RF modem
Wireless Range	1,000 ft (300 m) typical
Correction Factors	Integrated Correction Factor list of more than 700 compounds
Safety Certifications	UL/cUL: Class I, Div 1, Group A, B, C, D T4, -20°C ≤ Tamb ≤ +50°C (pending)
Temperature	-4° to 113°F (-20°C to 50°C)
Humidity	0% to 95% relative humidity (non-condensing)
Attachments	Durable rubber boot, color coded for different models; Tube holder for MP186 NEO BENZ
Warranty	2-year warranty including 10.6eV lamp and sensor; 1-year on 9.8eV lamp
