Vetter
Bypass Bags
Vetter bypass bags are inflatable pipe seals designed for fire services to safely seal or divert hazardous liquids and gases in pipes ranging from 100 to 1,200 mm.
Request a quote
Quotes typically returned within 1 business day.
- Woman-owned · HUB-certified
- Tax-exempt & POs accepted
Questions? Talk to a specialist210.566.1857 · sales@farrwest.com
Overview
Vetter bypass bags FS are pneumatic sealing devices designed to safely seal or divert pipes and protect sewage systems and groundwater from hazardous contamination. These bags allow controlled damming and diversion of hazardous liquids and gases using a fire hose. Individually adjustable to different line diameters, they are specifically engineered for fire service applications with exceptional resistance to chemicals and heat. Available in multiple pipe diameter configurations from 7-15 cm up to 80-140 cm.
- Safely seal pipes
- Divert hazardous liquids and gases
- Individually adjust to different line diameters
- Resistant to chemicals
- Resistant to heat
- Designed for fire services
Specifications
| Performance | |
| Air requirement at working pressure [l] | 9,5 |
| Test pressure | 1,95 bar / 28,28 psi |
| Operating pressure | 1,5 bar / 21,76 psi |
| Physical | |
| Weight | 0.5 kg |
| Pipe diameter | 7-15 cm / 2,76 - 5,91 in |
| Diameter | 6,8 cm / 2,68 in |
| Cylinder length | 30 cm / 11,81 in |
| Other | |
| Product number | 1482000700 |
