CAG RSTP 2.0 ATF
The CAG RSTP 2.0 ATF is a lightweight, multi-hit rifle ballistic plate for use with Level IIIA soft armor, independently tested to NIJ Standard 0106.01.
- Woman-owned · HUB-certified
- Tax-exempt & POs accepted
- Small (SAPI S) Weight
- 3.2 lbs (1.4 kg)
- Small (SAPI S) Dimensions
- 8.75"x11.75"
- Warranty - Ballistic Material
- 5 years
- Warranty - Exterior Cover and Workmanship
- 1 year
Overview
CAG RSTP 2.0 ATF is a multi-hit, lightweight ballistic plate engineered with a ceramic strike face and UHMWPE backing, covered in 500D Cordura®. Provides protection against Rifle Special Threat level threats when used in conjunction with Level IIIA soft armor. Independently tested by an NIJ-approved laboratory according to NIJ Standard 0106.01 (Modified SAPI). Features include 0.55″ thickness, available in SAPI cut with multi-curve design, and tested against multiple rifle threats including 7.62mm M80, 7.62x39mm mild steel core, 5.56mm M855 green tip, and 5.56mm M193. Backed by 5-year warranty on ballistic material and 1-year warranty on exterior cover and workmanship.
- Multi-hit capable
- Independently tested by NIJ-approved laboratory
- Lightweight design
- 0.55" profile
- Tested against 7.62mm NATO M80 at 2780 ft/s
- Tested against 7.62x39mm mild steel core at 2400 ft/s
- Tested against 5.56x45mm M855 at 3100 ft/s
- Tested against 5.56x45mm M193 at 3250 ft/s
- 500D Cordura® exterior covering
Specifications
| Physical | |
| Material | Ceramic strike face and UHMWPE backing |
| Small (SAPI S) Dimensions | 8.75"x11.75" |
| Small (SAPI S) Weight | 3.2 lbs (1.4 kg) |
| Medium (SAPI M) Dimensions | 9.5"x12.5" |
| Medium (SAPI M) Weight | 3.7 lbs (1.7 kg) |
| Large (SAPI L) Dimensions | 10"x13.25" |
| Large (SAPI L) Weight | 4.3 lbs (2.0 kg) |
| X-Large (SAPI XL) Dimensions | 11"x14" |
| X-Large (SAPI XL) Weight | 4.9 lbs (2.2 kg) |
| Approvals & Warranty | |
| NIJ Standard | 0106.01 |
| Warranty - Ballistic Material | 5 years |
| Warranty - Exterior Cover and Workmanship | 1 year |
| Other | |
| Protection Level | Rifle Special Threat Level ICW with Level IIIA Soft Armor |
| Exterior Cover | 500D Cordura® |
| Thickness | 0.55" or 14mm |
| Available Cuts | SAPI |
| Plate Curve | Multi Curve |
