ECAC and STAC EDS CB C3 approved
-
TSA APSS 6.2 Level 1 certified
-
Qualified on TSA Checkpoint Property Screening System (CPSS) Qualified Products List for base, mid and full-size configurations
-
Highest belt speed in its class at 0.2 m/s
-
5-20% lower power consumption compared to alternative systems
-
Low noise level of 60 dB with zero vibration
-
High detection rate and low false-alarm rate with MAT technology
-
Easily integrated into existing checkpoints with open architecture solutions
-
Optimized weight and footprint in Model S variant
-
Integration with iCMORE automated object recognition software
-
Eliminates need to remove electronic devices, liquids, and gels from hand luggage
-
Creates high-quality 3D images in real time
HI-SCAN 6040 CTiX
$0.00
The HI-SCAN 6040 CTiX is an advanced computed-tomography X-ray screening system for carry-on baggage inspection at airport security checkpoints.
The HI-SCAN 6040 CTiX is an advanced screening system for carry-on baggage using Computed Tomography (CT) and automatic explosives detection algorithms. ECAC EDS CB C3 approved and TSA APSS v6.2 Level 2 certified, it eliminates the need to remove electronic devices, liquids, and gels from hand luggage. The system features high-quality 3D real-time imaging with hundreds of images creating accurate assessments. The Model S offers a 20cm width reduction and 350kg weight reduction for easy integration into existing checkpoints. Key features include high throughput (0.2m/s belt speed), 5-20% lower power consumption, low noise (60dB), zero vibration, and optional iCMORE integration for automated prohibited item detection. Red Dot Award-winning user interface for fast and intuitive 3D image evaluation.
Description
HI-SCAN 6040 CTiX
The HI-SCAN 6040 CTiX is an advanced screening system for carry-on baggage using Computed Tomography (CT) and automatic explosives detection algorithms. ECAC EDS CB C3 approved and TSA APSS v6.2 Level 2 certified, it eliminates the need to remove electronic devices, liquids, and gels from hand luggage. The system features high-quality 3D real-time imaging with hundreds of images creating accurate assessments. The Model S offers a 20cm width reduction and 350kg weight reduction for easy integration into existing checkpoints. Key features include high throughput (0.2m/s belt speed), 5-20% lower power consumption, low noise (60dB), zero vibration, and optional iCMORE integration for automated prohibited item detection. Red Dot Award-winning user interface for fast and intuitive 3D image evaluation.
Features
Specifications
- Dimensions HI-SCAN 6040 CTiX
- 3,300 (L) x 1,670 (W) x 1,670 (H) [mm] / 129.9 (L) x 65.7 (W) x 65.7 (H) [in]
- Dimensions HI-SCAN 6040 CTiX Model S
- 3,300 (L) x 1,470 (W) x 1,624 (H) [mm] / 129.9 (L) x 57.9 (W) x 63.9 (H) [in]
- Weight HI-SCAN 6040 CTiX
- Approx. 2,450kg (5,401 lbs)
- Weight HI-SCAN 6040 CTiX Model S
- Approx. 2,099 kg (4,628 lbs)
- Tunnel dimensions
- 620 (W) x 420 (H) [mm] / 24.4 (W) x 16.5 (H) [in]
- Conveyor Speed
- 0.2 (m/s)
