Remote monitoring capabilities for toxic and oxygen sensors
-
Remote sensor mounting up to 100 feet (30m)
-
Sensor automatically configures transmitter
-
LCD and magnet switch operation without opening unit
-
Tri-color backlit LCD display (green steady, yellow flashing for fault, red flashing for alarm)
-
Two programmable alarm relays
-
One programmable fault relay
-
4-20mA output (sink or source selectable)
-
MODBUS communication
-
Fully configurable via magnetic switches
-
Auto-inhibit during maintenance
-
Available in flammable (catalytic or infrared), toxic, and oxygen versions
-
Stainless steel or aluminum explosion-proof housing options
-
IP66 rating
-
SurecellTM electrochemical sensors
-
Poison immune infrared sensors
-
Poison resistant catalytic bead sensors
-
Global approvals (UL, INMETRO, ATEX, IECEx, CSA, KTL, PA, GB, CCCF)
-
Plug-in sensor replacement
-
MODBUS multi-drop option
-
Integral mounting bracket
-
M20 or ¾ inch NPT cable/conduit entries
Sensepoint
$0.00
Honeywell Sensepoint is a fixed-point gas detector for industrial monitoring of flammable, toxic, and oxygen hazards in potentially explosive atmospheres.
In stock
Comprehensive fixed gas detector transmitter for monitoring combustible, toxic and oxygen gas hazards in potentially explosive atmospheres. Features remote sensor mounting capability (up to 100 feet), tri-color backlit LCD display with status indicators, plug-in sensor design with automatic configuration, and dual programmable alarm relays with 4-20mA output and MODBUS communication. Available in stainless steel or aluminum explosion-proof housing with IP66 rating. Includes proven SurecellTM electrochemical sensors, poison-resistant catalytic bead sensors, or poison-immune infrared sensors. Global certifications: UL, ATEX, IECEx, CSA, KTL, PA, GB standards.
Description
Sensepoint
Comprehensive fixed gas detector transmitter for monitoring combustible, toxic and oxygen gas hazards in potentially explosive atmospheres. Features remote sensor mounting capability (up to 100 feet), tri-color backlit LCD display with status indicators, plug-in sensor design with automatic configuration, and dual programmable alarm relays with 4-20mA output and MODBUS communication. Available in stainless steel or aluminum explosion-proof housing with IP66 rating. Includes proven SurecellTM electrochemical sensors, poison-resistant catalytic bead sensors, or poison-immune infrared sensors. Global certifications: UL, ATEX, IECEx, CSA, KTL, PA, GB standards.
Features
Specifications
- Brand
- Honeywell
- Product Type
- Industrial Gas
- Sub-Category
- Gas Detection Sensors & Transmitters
- Relay Included
- Yes
- Number of Relay Outputs
- 3
- Relay Output Configuration
- 3 x 5A @250 VAC
- Weight range
- 316 Stainless Steel: 11 lbs; Aluminium Alloy LM25: 4.4 lbs
- Minimum Temperature
- -40˚C
- Material
- 316 Stainless Steel
- Enclosure Material
- Epoxy Painted Aluminium Alloy ADC12 or 316 Stainless Steel
- Mounting
- Mounting Plate
- Conduit Entries
- (2) 3/4 in NPT
- Communication
- Modbus RTU; RS485
- Ingress Protection
- IP66
- Power Consumption
- Catalytic: 4.9W; Electrochemical Cells: 3.7W; IR: 3.7W
- Operating Voltage
- 12 to 32 VDC
- Industry
- Commercial Buildings; Energy; Manufacturing
Resources
