SP 555 E3 Spreader
The Hurst SP 555 E3 is a nimble, battery-powered spreader with integrated squeezing plates and smart E3 feedback.
- Woman-owned · HUB-certified
- Tax-exempt & POs accepted
Overview
The Hurst SP 555 E3 is a battery-powered spreader built for crews who need to move quickly on scene without being tied to a power unit.
It delivers strong spreading and pulling performance, with integrated squeezing plates adding versatility for extrication tasks. E3 smart feedback provides the operator with tool status information during use.
- Battery-powered, nimble design
- Strong spreading and pulling performance
- Integrated squeezing plates
- E3 smart feedback
Contact FarrWest for a quote.
- Lightweight, compact spreader for rapid deployment.
- 28.7 in (730 mm) spreading distance with strong force output.
- Watertight construction for fresh and salt water use.
- E3 smart dashboard with real-time visual feedback.
- “Shark Tooth” tips and built-in squeezing plates for versatile techniques.
- Max spreading force approx. 147,924 lbf / 658 kN.
- Spreading distance up to 28.7 in / 730 mm.
- High pulling force for controlled closing and pulling operations.
- Dashboard shows power, battery status and key alerts at a glance.
- Indicates when a saltwater-capable 9Ah E3 battery is installed.
- Turbo function available for faster rescue cycles.
- Single integrated cylinder body with squeezing plates built into the arms.
- “Shark Tooth” removable tips feature multiple rows of teeth for grip on high-strength steels.
- Supplied with two Li-ion batteries and a charger (per package configuration).
Specifications
| Power | |
| Battery Platform | E3 / EWXT 5Ah or 9Ah batteries |
| Physical | |
| Length | 36.3 in / 923 mm |
| Width | 10.4 in / 265 mm |
| Height | 9.96 in / 253 mm |
| Weight | Approx. 43.6 lb / 19.8 kg (tool only) |
| Approvals & Warranty | |
| NFPA HSF | 16,186 lbf / 72 kN |
| NFPA LSF | 11,016 lbf / 49 kN |
| NFPA HPF | 10,341 lbf / 46 kN |
| NFPA LPF | 6,295 lbf / 28 kN |
| Standard Compliance | NFPA 1960, 2024 edition (spreader) |
| Ingress Protection | IP58 tool rating |
| Other | |
| Model | SP 555 E3 Spreader |
| Spreading Distance | 28.7 in / 730 mm |
| Max Spreading Force | 147,924 lbf / 658 kN |
| Max Pulling Force | 13,039 lbf / 58 kN |
| Typical Package | Tool, two Li-ion batteries, one charger (package dependent) |
Media
SP 555 Spreader with E3 CONNECT
Hurst SP 555 E3 Spreader Overview
Description
Compact E3 spreader for fast extrication
The HURST SP 555 E3 Spreader is designed for those situations where speed and maneuverability are just as important as sheer force. Its compact dimensions and relatively low weight make it easy to position, even around cluttered vehicles and tight scenes, while still delivering serious spreading and pulling performance.
A smart E3 dashboard gives operators immediate visual feedback, including power level and battery state, and indicates when a salt-water capable battery is in use. The watertight design allows the SP 555 E3 to keep working in rain, snow or submerged conditions, making it a versatile choice for departments that face diverse environments.
Integrated squeezing plates plus removable “Shark Tooth” tips provide strong gripping performance and flexible techniques for peeling, spreading and pulling. Paired with HURST’s high-capacity 9Ah E3 batteries, this spreader is ready for repeated evolutions when seconds matter.
