Measurement of contamination and dose rate
-
Two simultaneous probe channels
-
Dual alpha/beta display for each probe
-
Customized alarm setpoint for each connected probe
-
Multiple measurement modes: Frisking, Scaler-Timer and Go/No-go
-
OneHand/OneFoot mode with body detection and automatic background management
-
Manual background deduction for net measurement of contamination
-
Backlit graphical digital display
-
Analog-like bar graph with digital display
-
Backup built-in rechargeable battery with no memory effect
-
Rugged, lightweight and easy to use
-
Upgradable product through firmware upgrade
AVIOR-2 Desktop Dose Rate & Survey Meter
$0.00
The AVIOR-2 is a versatile desktop dose rate and survey meter for contamination control at laboratories, industrial sites, nuclear power plants, and emergency response situations.
In stock
The AVIOR-2 is a versatile alarm desktop, portable, or wall-mounted dose rate and survey meter for contamination control and dose-rate assessment. Equipped with two Canberra Smart Probe (CSP) inputs with simultaneous dual-channel display, it provides discriminated alpha/beta measurements for rapid contamination detection. Features include multiple measurement modes (Frisking, Scaler-Timer, Go/No-go), dedicated OneHand/OneFoot mode for limited-footprint areas, manual background deduction, backlit graphical display with analog-like bar graph, rechargeable battery, and firmware upgrade capability. Designed for laboratories, industrial sites, nuclear power plants, and emergency situations.
Description
AVIOR-2 Desktop Dose Rate & Survey Meter
The AVIOR-2 is a versatile alarm desktop, portable, or wall-mounted dose rate and survey meter for contamination control and dose-rate assessment. Equipped with two Canberra Smart Probe (CSP) inputs with simultaneous dual-channel display, it provides discriminated alpha/beta measurements for rapid contamination detection. Features include multiple measurement modes (Frisking, Scaler-Timer, Go/No-go), dedicated OneHand/OneFoot mode for limited-footprint areas, manual background deduction, backlit graphical display with analog-like bar graph, rechargeable battery, and firmware upgrade capability. Designed for laboratories, industrial sites, nuclear power plants, and emergency situations.
Features
Specifications
- Units displayed (depending on probe)
- c/s, Bqeq, Bqeq/cm², Sv/h, Sveq/h
- Alarm threshold
- CSP probe: 10 values for each unit to display, stored in probe memory. Each value is editable via PC setup Canberra Smart Probe Software (CSPS™) or directly on the AVIOR-2 meter
- Response time
- As fast as 1/4 s for bargraph display depending on probe, on a semi-logarithmic scale; 1 s for clear digital readout display
- Built-in rechargeable battery
- Li-ion battery pack
- Battery Life with Backlight (Maximum/turned off)
- 31/70 hours with one SAB-100 probe connected, 29/60 hours with SA-100 and SB-100 probes connected
- Built-in charger
- Yes
- Universal Mains power input
- 100–240 V ac, 50/60 Hz. Rear-panel IEC-type connector. Cordset included.
- Display of remaining charge
- Battery pictogram
- Operating temperature
- -10 °C to +50 °C. Between -10 °C and -20 °C, the instrument remains operational but the display becomes more difficult to read.
- Storage temperature
- -25 °C to + 60 °C
- Ingress protection
- IP54
- Housing
- Molded rugged Polycarbonate
- Dimensions
- 184 x 105 x 105 mm (7.2 x 4.1 x 4.1 in.) (L x W x H)
- Weight
- 950 g (33.5 oz), battery included
- Connector for external probes
- S 104 A066 137+ Fisher socket (CSP) or equivalent
- Two simultaneous CSP probe channels
- Yes
- Specific OneHand/OneFoot mode
- With body detection and automatic background management
- Grand display
- Large LCD display with constant backlight
- Audible alarm
- > 85 dB(A) at 30 cm (11.8 in.)
- Visual alarm
- Flashing alarm pictogram and LED for each channel (Red, orange, green)
- Keyboard
- Ruggedized keyboard with five buttons featuring primary and secondary functions: Enter (Power on), Up arrow (Backlight), Down arrow (Audio on/off), Left arrow (Lock), Right arrow (Data Log)
- Operating control
- Complete and automatic self-test when switching on. Periodical self-control of key operational functions when operating
- Wall mounting
- Back panel with dedicated print for wall accessory
- EMC
- Conform
- IEC
- Conform to IEC60846-2002 and IEC60325-2006
- CE
- Conform
