Auto-ranging with best measurement range and resolution
-
High resolution 40A range
-
Measures AC current, AC and DC voltage, resistance, continuity with beeper, and frequency
-
Diode test function
-
MIN/MAX/PEAK-/PEAK+ measurement capability
-
Relative measurement (∆REL) function
-
Average sensing designed for traditional average responding electrical systems
-
Rugged mechanical case with quality polycarbonate materials
-
Comfortable one-handed operation
-
Compliant with international safety and quality standards
Clamp-On Meter Model 511
$0.00
AEMC INSTRUMENTS Clamp-On Meter Model 511 is a rugged one-handed AC clamp meter for field current and continuity verification by electrical professionals.
In stock
The Clamp-on Meter Model 511 is a general purpose professional instrument designed for tough measurement standards. Built with rugged mechanical case and quality polycarbonate materials, it offers a complete set of measurement ranges compliant with international safety and quality standards. Features auto-ranging capability for best measurement range and resolution. The Model 511 measures AC current (up to 1000Arms), AC and DC voltage (750V AC, 1000V DC), resistance, continuity with beeper, frequency from V or A, and diode test function. Sized for comfortable one-handed operation, it is average sensing for traditional electrical systems with 1.575″ (40mm) jaw opening. Includes soft carrying case, test leads with probe tips, 9V battery, and user manual.
Description
Clamp-On Meter Model 511
The Clamp-on Meter Model 511 is a general purpose professional instrument designed for tough measurement standards. Built with rugged mechanical case and quality polycarbonate materials, it offers a complete set of measurement ranges compliant with international safety and quality standards. Features auto-ranging capability for best measurement range and resolution. The Model 511 measures AC current (up to 1000Arms), AC and DC voltage (750V AC, 1000V DC), resistance, continuity with beeper, frequency from V or A, and diode test function. Sized for comfortable one-handed operation, it is average sensing for traditional electrical systems with 1.575″ (40mm) jaw opening. Includes soft carrying case, test leads with probe tips, 9V battery, and user manual.
Features
Specifications
- Voltage Range
- 750V AC, 1000V DC Auto-Ranging
- Resolution Max (Voltage)
- 0.1V
- Current Range
- 1000Arms AC
- Resolution Max (Current)
- 0.01A
- Accuracy V Typical
- 1.2% ± 5cts
- Accuracy A Typical
- 1.9% ± 5cts
- Continuity
- <40Ω
- Resistance
- 400Ω
- Diode
- Yes
- Frequency
- 10kHz in V, 4kHz in A
- MIN/MAX/PEAK-/PEAK+
- Yes
- ∆REL
- Yes
- Power Source
- 1 x 9V, IEC 6LR61
- Battery Life
- 150 hours
- Dimensions
- 9.53 x 2.6 x 1.42″ (242 x 66 x 36mm)
- Weight
- 14.1 oz. (400g) with battery
- Jaw Opening
- 1.575″ (40mm)
- Operating Temperature
- +32° to 104°F (0° to +40°C)
- Storage Temperature
- +14° to 140°F (-10° to +60°C)
- Operating Humidity
- 80% up to 104°F (40°C)
- Pollution Degree
- 2
- Safety Compliance
- EN/IEC 61010 to 600V CAT III, 1000V CAT II
