Hydraulic lift capacity of 10 U.S. tons with 2:1 safety factor
-
20,000 lbs. stabilization with 4:1 safety factor via threaded collar
-
Adjustable in any increment up to maximum strut length
-
No-spill, flat-faced, quick-connect hydraulic coupling
-
360 degree swivel fitting
-
Dual shaft end adapter for AcmeThread, LockStroke or LongShore compatibility
-
Clear load chart and extension length labels
-
Hand operated dual stage pump with protected pressure gauge
-
All metal pump construction with locking arm mechanism
Paratech HydraFusion Strut
$0.00
The Paratech HydraFusion Strut is a hybrid shoring and hydraulic-lift strut for rescue and structural stabilization operations, offering 10 tons of lift capacity and 20,000 lbs of stabilization force.
The Paratech HydraFusion Strut features a 3″ diameter threaded aluminum shaft extending hydraulically from a 3.5″ diameter aluminum tube. It provides 10 U.S. tons of hydraulic lift capacity with a 2:1 safety factor. Once extended, the AcmeThread collar locks down to create a 20,000 lbs stabilization force with a 4:1 safety factor. The strut uses a simple ‘EXTEND & SPIN TO LOCK’ operation and allows fine adjustments in any increment up to maximum length. Available in three stroke sizes (4″, 10″, and 16″) with accompanying pump and adapter options.
Description
Paratech HydraFusion Strut
The Paratech HydraFusion Strut features a 3″ diameter threaded aluminum shaft extending hydraulically from a 3.5″ diameter aluminum tube. It provides 10 U.S. tons of hydraulic lift capacity with a 2:1 safety factor. Once extended, the AcmeThread collar locks down to create a 20,000 lbs stabilization force with a 4:1 safety factor. The strut uses a simple ‘EXTEND & SPIN TO LOCK’ operation and allows fine adjustments in any increment up to maximum length. Available in three stroke sizes (4″, 10″, and 16″) with accompanying pump and adapter options.
Features
Specifications
- Tube diameter
- 3 1/2″ diameter aluminum
- Shaft diameter
- 3″ diameter threaded aluminum
- Lift capacity
- 10 U.S. tons
- Lift safety factor
- 2:1
- Stabilization load
- 20,000 lbs.
- Stabilization safety factor
- 4:1
- Tube material
- 3.5″ (8,89 cm) diameter extruded aluminum alloy seamless tube
- Maximum pressure
- Up to 10,000 psi (690 bar)
- Hydraulic coupling
- No-spill, flat-faced, quick-connect on 360 degree swivel fitting
- Available stroke sizes
- 4 in (10,2 cm), 10 in (25,4 cm), 16 in (40,4 cm)
- Hose length
- 10 ft (3 m) non-conductive kink-resistant hose
