Remote sampling capability allowing operation from safe distance
-
Low flow alarm activation when air flow is compromised
-
Independent power supply separate from G450 detector
-
Automatic shutoff when battery voltage falls below minimum level
-
Battery capacity indicator on instrument display
-
Compatible with multiple approved battery pack models
-
Magnet-controlled on/off operation via blue sensor cover
-
Continuous system monitoring with fault recognition
-
Support for sampling line lengths up to 100 meters
Attachable motorized pump module
$0.00
The G400 MP-2 is a clip-on motorized pump module for the G450 portable gas detector that enables safe remote atmospheric sampling from a distance.
In stock
The G400 MP-2 is a compact motorized pump module designed for remote atmospheric sampling in conjunction with the G450 portable gas detector. It enables safe gas sampling from a distance without exposing users to hazardous atmospheres. Features independent power supply, magnetic on/off operation, and draws samples at 1 foot per second (1 meter per 3 seconds). MSHA approved for use with specified battery packs. Includes sampling inlet with connection for hose adapters, probes, and telescopic sampling accessories.
Description
Attachable motorized pump module
The G400 MP-2 is a compact motorized pump module designed for remote atmospheric sampling in conjunction with the G450 portable gas detector. It enables safe gas sampling from a distance without exposing users to hazardous atmospheres. Features independent power supply, magnetic on/off operation, and draws samples at 1 foot per second (1 meter per 3 seconds). MSHA approved for use with specified battery packs. Includes sampling inlet with connection for hose adapters, probes, and telescopic sampling accessories.
Features
Specifications
- Type
- G400 MP-2 Motorized Pump
- Pump performance
- 0.50 l/min for 0 mm water column; 0.35 l/min for 300 mm water column; Maximum 100 m hose length (depending on gas and hose)
- Gas supply
- Sampling inlet during pump mode or diffusion inlet
- Power supply
- NiMH battery module, rechargeable Im=1 A (maximum charging current) Um=3 V DC (maximum charge voltage) or Alkaline battery module, non-rechargeable with 2x size AA Duracell MN1500 LR6
- Operational time
- Approximately 10 hours
- Operation climate
- -4 to 131°F (-20 to +55°C) / 5 to 95% r.h.
- Storage climate
- -13 to 131°F (-25 to +55°C) / 5 to 95% r.h. (recommended: 32 to 86°F (0 to +30°C))
- Casing material
- Rubberized compound
- Dimensions
- 4.29 x 2.68 x .83 inches (109 x 68 x 21 mm) (H x W x D)
- Weight
- 6.35 ounces (180 g) with alkaline battery module
- Protection
- IP40
