True InRush measurement
-
Harmonic analysis up to 25th
-
AC, DC, and AC+DC measurements
-
Power measurements and power factor
-
Data logging with up to 1000 points (160 hours at 10-minute intervals)
-
Bluetooth connectivity
-
THD calculation (%f and %r)
-
MIN/MAX/PEAK recording
-
Single-hand ergonomic operation
-
1000V CAT IV safety rating
-
IP54 dust and water resistance
-
DataView software included
Power Clamp-On Meter Model 407
$0.00
The AEMC Instruments Power Clamp-On Meter Model 407 is a comprehensive power analyzer for electrical professionals requiring TRMS measurements up to 1000A AC with harmonic analysis and Bluetooth data logging.
In stock
The TRMS Power Clamp-on Meter Model 407 is a comprehensive power analyzer designed for demanding electrical work environments. Safety rated at 1000V CAT IV with IP54 dust and water resistance, it features ergonomic one-handed operation. Capabilities include AC/DC/AC+DC voltage and current measurement (up to 1000V, 1000A AC, 1500A DC), power measurements up to 1MW AC/3MW DC, harmonic analysis up to 25th harmonic, THD measurement, True InRush® detection, data logging (up to 1000 points), Bluetooth connectivity, and DataView software integration. Includes hard carrying case, test leads, probes, alligator clips, USB adapter, batteries, and software.
Description
Power Clamp-On Meter Model 407
The TRMS Power Clamp-on Meter Model 407 is a comprehensive power analyzer designed for demanding electrical work environments. Safety rated at 1000V CAT IV with IP54 dust and water resistance, it features ergonomic one-handed operation. Capabilities include AC/DC/AC+DC voltage and current measurement (up to 1000V, 1000A AC, 1500A DC), power measurements up to 1MW AC/3MW DC, harmonic analysis up to 25th harmonic, THD measurement, True InRush® detection, data logging (up to 1000 points), Bluetooth connectivity, and DataView software integration. Includes hard carrying case, test leads, probes, alligator clips, USB adapter, batteries, and software.
Features
Specifications
- Voltage Range
- 1000 Vrms AC/DC / AC+DC Autoranging
- Resolution Max Voltage
- 0.01 V
- Current Range
- 1000 Arms AC, 1500 ADC
- Resolution Max Current
- 0.01 A
- Accuracy V Typical
- 1 % ± 3 cts
- Accuracy A Typical
- 1 % ± 3 cts
- InRush
- (10 to 1000) AAC, 10 to 1500 ADC
- Power Measurement Max
- 1 MW AC, 3 MW DC
- Harmonics
- Up to 25th
- THD
- Yes, %f and %r
- Continuity
- Selectable from 0 to 999.9 Ω
- Resistance
- 100 kΩ
- Frequency
- V: 20 kHz, A: 2 kHz
- Power Factor
- Yes
- MIN/MAX/PEAK-/PEAK+
- Yes
- ΔREL
- Yes
- Recording
- Yes, up to 1000 points (160 h at 10 min intervals)
- Communication
- Bluetooth
- Software
- Yes, DataView included
- Power Source
- (4) AA, NEDA 15 A, IEC LR6
- Battery Life
- > 350 h
- Dimensions
- (10.7 x 3.6 x 1.6) in (272 x 92 x 41) mm
- Weight
- 1.32 lbs (600 g) with batteries
- Jaw Opening
- 1.9in (48 mm)
- Operating Temperature
- (-4 to +131) °F (-20 to +55) °C
- Storage Temperature
- (-40 to +158) °F (-40 to +70) °C
- Operating Humidity
- 90 % up to 131 °F (55 °C)
- Pollution Degree
- 2
- Ingress Protection
- IP54
- EMC
- EN61326-1
- Safety Compliance
- EN/IEC 61010-1 to 1000V CAT IV, EN/IEC 61010-2-030:2010, EN/IEC 61010-032:2002
