Clamp-on ground resistance measurement without auxiliary rods
-
Operates on multi-grounded systems without disconnecting or de-energizing
-
Measures ground rod and grid resistance and impedance
-
Verifies quality of grounding connections and bonds
-
Measures resistance and continuity of grounding loops
-
Auto-ranging ground resistance measurement (1 to 199Ω)
-
Auto-ranging current measurement
-
Loop inductance measurement
-
Contact voltage (touch voltage) calculated measurement
-
Adjustable alarm for resistance, voltage, and current
-
Frequency selection (50, 60, 128, or 2083 Hz) for impedance calculation
-
OLED display with 152 segments
-
2000 measurement memory capacity
-
Bluetooth communication with DataView software
-
Android app available
-
Jaw opening 1.38 in (35mm) max
Clamp-On Ground Resistance Tester Model 6417
$0.00
The AEMC Model 6417 is a clamp-on ground resistance tester for safety professionals to measure grounding systems without auxiliary rods or de-energizing equipment.
In stock
The Ground Resistance Tester Model 6417 measures ground rod and grid resistance and impedance without the use of auxiliary rods. This clamp-on ground resistance tester can be used in multi-grounded systems without disconnecting or de-energizing the ground system under test. The Model 6417 simply clamps around the grounding electrode or conductor and measures the resistance to ground. By performing measurements on intact ground systems, users verify the quality of grounding connections and bonds. Resistance and continuity of grounding loops around pads and buildings may also be measured. Features include auto-ranging ground resistance measurement (1-199Ω), current measurement capability, loop inductance measurement, contact voltage calculation, OLED display, 2000-measurement memory, Bluetooth connectivity with DataView software, adjustable alarms, and IP40 ingress protection. Includes hard carrying case, calibration loop, Bluetooth USB adapter, batteries, quick start guide, and USB thumb drive with software and user manual.
Description
Clamp-On Ground Resistance Tester Model 6417
The Ground Resistance Tester Model 6417 measures ground rod and grid resistance and impedance without the use of auxiliary rods. This clamp-on ground resistance tester can be used in multi-grounded systems without disconnecting or de-energizing the ground system under test. The Model 6417 simply clamps around the grounding electrode or conductor and measures the resistance to ground. By performing measurements on intact ground systems, users verify the quality of grounding connections and bonds. Resistance and continuity of grounding loops around pads and buildings may also be measured. Features include auto-ranging ground resistance measurement (1-199Ω), current measurement capability, loop inductance measurement, contact voltage calculation, OLED display, 2000-measurement memory, Bluetooth connectivity with DataView software, adjustable alarms, and IP40 ingress protection. Includes hard carrying case, calibration loop, Bluetooth USB adapter, batteries, quick start guide, and USB thumb drive with software and user manual.
Features
Specifications
- Model
- 6417
- Cat. #
- 2141.02
- Ground Resistance Measurement Range
- 1 to 199Ω (auto-ranging)
- Ground Resistance – (0.010 to 0.099) Ω Resolution
- 0.001 Ω
- Ground Resistance – (0.010 to 0.099) Ω Accuracy
- ±(1.5 %Reading +0.01 Ω)
- Ground Resistance – (0.10 to 0.99) Ω Resolution
- 0.01 Ω
- Ground Resistance – (0.10 to 0.99) Ω Accuracy
- ±(1.5 %Reading +0.02 Ω)
- Ground Resistance – (1 to 49.9) Ω Resolution
- 0.1 Ω
- Ground Resistance – (1 to 49.9) Ω Accuracy
- ±(1.5 % Reading +0.1 Ω)
- Ground Resistance – (50.0 to 99.5) Ω Resolution
- 0.5 Ω
- Ground Resistance – (50.0 to 99.5) Ω Accuracy
- ±(2 % Reading +0.5 Ω)
- Ground Resistance – (100 to 199) Ω Resolution
- 1 Ω
- Ground Resistance – (100 to 199) Ω Accuracy
- ±(3 % Reading +1 Ω)
- Ground Resistance – (200 to 395) Ω Resolution
- 5 Ω
- Ground Resistance – (200 to 395) Ω Accuracy
- ±(5 % Reading +5 Ω)
- Ground Resistance – (400 to 590) Ω Resolution
- 10 Ω
- Ground Resistance – (400 to 590) Ω Accuracy
- ±(10 % Reading +10 Ω)
- Ground Resistance – (600 to 1150) Ω Resolution
- 50 Ω
- Ground Resistance – (600 to 1150) Ω Accuracy
- 20 % approx.
- Ground Resistance – (1200 to 1500) Ω Resolution
- 50 Ω
- Ground Resistance – (1200 to 1500) Ω Accuracy
- 25 % approx.
- Alarm
- Adjustable from (1 to 199) Ω
- Frequency Selection
- Choice of (50, 60, 128, or 2083) Hz for impedance calculation
- Maximum Overload – Permanent current
- 100 A max. 50/60 Hz
- Maximum Overload – Transient current
- (<5 s) 200 A 50/60 Hz
- Current Measurement Range
- Auto-ranging
- Current – (0.200 to 0.999) mA Resolution
- 1µ A
- Current – (0.200 to 0.999) mA Accuracy
- ±(2 % Reading +50 µA)
- Current – (1.000 to 2.990) mA Resolution
- 10 µA
- Current – (1.000 to 2.990) mA Accuracy
- ±(2 % Reading +50 µA)
- Current – (3.00 to 9.99) mA Resolution
- 10 µA
- Current – (3.00 to 9.99) mA Accuracy
- ±(2 % Reading +50 µA)
- Current – (10.00 to 29.99) mA Resolution
- 100 µA
- Current – (10.00 to 29.99) mA Accuracy
- ±(2 % Reading +100 µA)
- Current – (30.0 to 99.9) mA Resolution
- 100 µA
- Current – (30.0 to 99.9) mA Accuracy
- ±(2 % Reading +100 µA)
- Current – (100 to 299.9) mA Resolution
- 1 mA
- Current – (100 to 299.9) mA Accuracy
- ±(2 % Reading +1 mA)
- Current – (0.300 to 0.990) A Resolution
- 1 mA
- Current – (0.300 to 0.990) A Accuracy
- ±(2 % Reading +1 mA)
- Current – (1.000 to 2.999) A Resolution
- 10 mA
- Current – (1.000 to 2.999) A Accuracy
- ±(2 % Reading +10 mA)
- Current – (3.00 to 39.99) A Resolution
- 10 mA
- Current – (3.00 to 39.99) A Accuracy
- ±(2 % Reading +10 mA)
- Loop Inductance – (10 to 100) µH Resolution
- 1 µH
- Loop Inductance – (10 to 100) µH Accuracy
- ±(5 % Reading +1 µH)
- Loop Inductance – (100 to 500) µH Resolution
- 1 µH
- Loop Inductance – (100 to 500) µH Accuracy
- ±(3 % Reading +1 µH)
- Contact Voltage – (0.1 to 4.9) V Resolution
- 0.1 V
- Contact Voltage – (0.1 to 4.9) V Accuracy
- ±(5 % Reading +0.1 V)
- Contact Voltage – (5.0 to 49.5) V Resolution
- 0.5 V
- Contact Voltage – (5.0 to 49.5) V Accuracy
- ±(5 % Reading +0.5 V)
- Contact Voltage – (50 to 75.0) V Resolution
- 1 V
- Contact Voltage – (50 to 75.0) V Accuracy
- ±(10 % Reading +1 V)
- Display
- OLED, 152 segments (48×39) mm
- Memory
- 2000 measurements
- Communication
- Bluetooth, DataView software included
- Alarms
- 3 separate alarms (Ω, V and A)
- Power Source
- (4) x1.5 V LR6 (AA) alkaline batteries or 4 NiMH batteries
- Battery Life
- 12 hours or 1440 30-seconds tests approx.
- Jaw Opening
- 1.38 in (35mm) max
- Dimensions
- (2.16 x 3.74 x 10.31) in (55 x 95 x 262) mm
- Weight (with Battery)
- 2.06 lbs (935 g)
- Operating Temperature
- (-4° to +131) °F (-20 to +55) °C
- Storage Temperature
- (-22° to +158) °F (-30 to +70) °C
- Relative Humidity
- Up to 90 % @ 40 °C
- Ingress Protection (IP)
- IP 40
- EMC
- EN 61326-1
- Safety Compliance
- IEC 61010-1, EN 61010-2-30, EN 61010-2-32, Pollution Degree 2, 600 V CAT IV
