FLIR Scion PTM466 (60Hz) Thermal Monocular – 640×512, 36mm Lens, IP67 Rated

Name: FLIR Scion PTM466 (60Hz) Thermal Monocular – 640x512, 36mm Lens, IP67 Rated
Brand: FLIR

$0.00

The FLIR Scion PTM466 is a 640×512 thermal monocular with a 36mm lens, 8x digital zoom, and IP67 rugged protection for tactical field use.

In stock

The FLIR Scion PTM466 (60Hz) Thermal Monocular delivers 640×512 thermal resolution through a 36mm lens, giving operators clear thermal imagery for tactical field operations.

It includes 8x digital zoom and is IP67 rated, providing rugged protection against dust and water for use in demanding field environments.

640×512 thermal resolution
36mm lens
8x digital zoom
IP67 rated (60Hz refresh)

Contact FarrWest for a quote.

Description

Scion PTM466

Situational Awareness. Real-Time Surveillance. Mission-Ready Thermal Imaging.

The FLIR Scion PTM466 (60Hz) is engineered to support law enforcement, military, and search-and-rescue teams with advanced thermal surveillance technology in a compact, rugged package. Outfitted with a crisp 36mm objective lens and a 640 × 512 uncooled thermal sensor with 12-micron pixel pitch, this monocular delivers high-resolution imagery that remains clear and stable, even during rapid movements or vehicle pursuits.

With a 60Hz refresh rate, 8× digital zoom, and 12° × 9° field of view, the PTM466 ensures unmatched clarity and target recognition at extended distances, while picture-in-picture (PIP) zoom preserves your situational awareness in fast-moving environments. Designed for the toughest missions, the Scion PTM466 is IP67-rated for full protection against dust, water, and shock. It weighs only 680 grams and measures 278 x 77 x 73mm, making it highly portable and mission-ready. With 16mm eye relief for comfortable extended viewing and encrypted video streaming, you can instantly share geotagged thermal footage with command teams over a secure wireless network.

Features

Live (Encrypted) Video Streaming
Picture in Picture (PIP) zoom
60Hz Framerates
FLIR’s Boson Thermal core
Rich User Interface

Live Encrypted Video Streaming

Securely stream real-time thermal video to the command center via networked devices Link powerful Scion PTM thermal imaging to integrated devices via Wi-Fi and network with other deployed smart sensors on the scene for enhanced, real-time situational awareness and centralized public safety information

Versatile Lens Options

Available long-range lenses for the Scion family of thermal monoculars offers a new level of clarity and reach. High-performance thermal lenses ranging from 14-36 mm offer a choice between quick, closeproximity detection and fine-tuned, long-range surveillance. When the mission demands reliable vision from a distance, premium Scion lenses can detect targets up to 1420 m away. 25 mm and 36 mm Scion optics leverage a manual focus ring to achieve a new level of clarity among FLIR thermal monoculars.

Superior Thermal Detection

Sharp, 60 Hz thermal imaging powered by the breakthrough FLIR Boson™ thermal core FLIR outfits law enforcement professionals with tools to counter unseen threats. Able to perform at any time of day, thermal imaging pierces complete darkness, glaring light, and lingering haze to provide superior awareness in difficult conditions. The advanced image processing of FLIR’s Boson thermal core paired with a 60 Hz image refresh rate provide smooth, unwavering vision in challenging environments.

Specifications

General
Core Technology: BOSON 12 µm VOx Microbolometer
Detector Resolution: 640 × 512
Lens System: 36 mm
Field of View (H x W): 12°× 9°
Optical Magnification: 2.0x
Digital Zoom: 1X | 2X | 4X | 8X
Refresh Rate: 60 Hz
Video Recording: Yes
Focus: Manual
Eye Relief: 16 mm
Display: Quad-VGA (1280×960) High definition display
Display Focus: Manual
Interfacing
USB Type: USB-C; Power In; Video Out; Video and Image File Transfer

Features
Color palettes: White Hot; Black Hot; Iron Bow; Rainbow; Graded Fire; Lava
Viewing Modes: Scouting, Picture-in-Picture, Lock Span mode
Picture While Recording (PWR): Yes
Media capturing: 2 GB Internal storage / Optional micro SD™ card (up to 128 GB)
GPS: Yes
Real Time Clock (RTC): Yes
Date/Time Stamp: Yes
Auto Power OFF: Yes
Magnetic Compass: Yes
Accelerometer: Yes
Power
Battery Type / Life: 6x CR123A 3V Lithium Battery / Up to 4.5 Hours at 20°C or Rechargeable battery pack / Up to 10 Hours at 20°C

Communications
Bluetooth: BLE 4.1+
Wi-Fi: Video Steaming
NFC: Yes
Physical
Weight: Unit only: 680g
With Batteries (6): 793g
Size: 278 x 77 x 73mm
(10.9 x 3.03 x 2.87)
Environmental rating: IP67 waterproof / 2m drop
Operating Temperature: -20°c to 50°c
Storage Temp.: -40°c to 70°c
Color (Housing): Black
Mounting: ¼-20 Tripod Mount
Country of Origin: USA
Included in Box: SCION, Battery tray, 6xCR123, USB-C cable,
Black MOLLE pouch, Quick Start Guide

Resources

Scion PTM466 Datasheet
