RadEye NL
The RadEye NL is a compact, lightweight personal neutron radiation detector designed for personnel working in nuclear facilities and accelerator environments.
- Woman-owned · HUB-certified
- Tax-exempt & POs accepted
- Calibration & repair
Overview
The RadEye™ NL Personal Highly Sensitive Neutron Radiation Detector is a compact, lightweight neutron detector designed for personnel working with neutron radiation sources. Features include rapid warning of neutron radiation fields, high sensitivity for neutron detection (exceeds ISO 22188 requirements), excellent gamma rejection (no spill-over up to 10 mSv/h), and hands-free operation when worn in an optional holster. The 160g detector uses a He-3 counting tube with 2.5 bar filling pressure, making it airline-transportable. It includes a clear display, 85 dB alarm at 30cm distance, IR/Bluetooth communication, and can log 250 alarms and 1600 history entries. Ideal for industrial neutron source operators, accelerator users, radiation protection staff, nuclear facility inspectors, first responders, and law enforcement.
- High sensitivity for neutron radiation with rapid warning of neutron radiation fields
- Applicable as an Area Monitor
- Exceeds the neutron response requirements of ISO 22188
- Ideal complement to passive and active neutron dosimeters
- 160g lightweight with low power technology
- Can be worn and operated in holster
- Hands-free operation with no restriction of personal mobility
- Rapid scanning of changing field intensities
- Detection of neutron shielding deficiencies and source presence
- No spill-over from gamma radiation up to 10 mSv/h (1 R/h)
- No false 'Neutron Alarm'
- Can be used in high gamma dose rate fields
- Battery powered (2 x AAA alkaline or rechargeable)
- Operating hours: approx. 500 h
- Alarms 85 dB at distance of 30cm (11.8 in.)
- Clear and large display
- Communication interface: Infrared (IR), optional IR to USB cable or IR to serial cable, optional Bluetooth
- Settings and data analysis done by optional Windows based PC-software via serial data connection, USB or Bluetooth
- Logs last 250 alarms, error messages and changes of configuration
- 1600 history data entries with user adjustable time interval
Specifications
| Performance | |
| Detector Type | He-3 tube with 2.5 bar filling pressure |
| Sensitivity | When worn at the body, RadEye NL: approx. 0.2 cps/µSv/h (2 cps/mRem/h) for Cf-252, detects 0.01 µg Cf-252 in typically 2 to 3 s for 10 in. (25cm) distance |
| Background Measurement | approx 0.003 cps at 300m above sea level |
| Physical | |
| Dimensions (L x W x H) | 3.8 x 2.4 x 1.2 in. (9.6 x 6.1 x 3.1 cm) |
| Height (English) | 1.2 in. |
| Length (English) | 3.8 in. |
| Length (Metric) | 9.6 cm |
| Weight (English) | 5.6 oz. |
| Width (English) | 2.4 in. |
| Height (Metric) | 3.1 cm |
| Weight (Metric) | 160 g |
| Width (Metric) | 61 mm |
| Unit Size | Each |
| Approvals & Warranty | |
| Certifications/Compliance | Exceeds the neutron response requirements of ISO 22188. |
| Other | |
| Description | Highly Sensitivie |
| For Use With (Application) | Users of industrial neutron sources (e.g., in geology and material testing), operators and users of accelerators in medical science and research, radiation protection staff and inspectors of nuclear facilities, and first responders and law enforcement officers |
| Gamma Spill-Over | <0.2 cps at 10 mSv/h (1 R/h) Cs-137 radiation |
| Units | Count rate (cps) moving average over 10 s |
| Product Type | Personal Radiation Detector |
