Honeywell UltraRAE 3000+ – Benzene & VOC Compound-Specific Monitor with Extended PID Detection

Name: Honeywell UltraRAE 3000+ – Benzene & VOC Compound-Specific Monitor with Extended PID Detection
Brand: Honeywell

$0.00

Honeywell UltraRAE 3000+ is a benzene and VOC compound-specific monitor with extended PID detection and dual detection modes for hazmat and refinery safety.

In stock

The Honeywell UltraRAE 3000+ is built to detect volatile organic compounds (VOCs) and benzene specifically, using PID technology for accurate compound-specific readings.

Dual detection modes and real-time readouts give hazmat and refinery teams flexibility, and pre-tube technology supports benzene-specific measurement in environments where that distinction matters most.

Compound-specific benzene and VOC detection
Dual detection modes with real-time readings
Pre-tube technology for benzene-specific PID accuracy

Contact FarrWest for a quote.

Description

UltraRAE 3000+

Advanced Benzene Detection. Trusted VOC Monitoring. Real-Time Results.

The Honeywell UltraRAE 3000+ is one of the most advanced compound-specific monitors available, designed to deliver precise, real-time detection of volatile organic compounds (VOCs) and benzene, even at extremely low concentrations. Featuring an extended-range photoionization detector (PID) and dual-mode benzene detection, the UltraRAE 3000+ is essential for professionals working in hazardous environments such as refineries, chemical plants, spill response, and hazmat operations.

With a VOC detection range of 0.01 to 10,000 ppm and benzene-specific sensitivity as low as 10 ppb, this instrument enables early detection and safer decision-making. The UltraRAE 3000+ offers both a 60-second spot check and a 15-minute STEL (Short-Term Exposure Limit) monitoring mode, allowing users to quickly assess conditions or track longer-term exposure.

Using RAE Systems’ proprietary pre-tube filter technology, the UltraRAE 3000+ eliminates many of the inaccuracies found in older colorimetric tubes and gas chromatographs—delivering fast, reliable data you can trust in high-stakes situations.

Features

Versatile VOC or Benzene-Specific modes
Reflex PID Technology
Built-in humidity sensor with Automatic temperature-controlled
sampling time calculation
Highly connectivity capability through multiple wireless module
options

Reliable Alarm System

Lower risk of false alarms through
advanced speciation method

Great Design

Intuitive, icon-driven interface and Large buttons for easy navigation even with up to three glove layers

Dual Detection Mode

Dual detection mode for total benzene
exposure assessment: 60-second snapshot
or 15-minute STEL measurement

Very Effiecient

High sensitivity to benzene provides
a lower detection range for future
benzene exposure limits

Specifications

Specifications

Size

10” L x 3.0” W x 2.5” H (25.5 x 7.6 x 6.4 cm)

Weight

26 oz (738 g)

Sensors

Photoionization sensor with standard 9.8 eV or optional 10.6 eV or 11.7 eV lamps

Running Time

16 hours of operation

Alarms

95dB buzzer at 12” (30 cm) and flashing red LED to indicate exceeded preset limits: High: 3 beeps and flashes per second; Low: 2 beeps and flashes per second; STEL and TWA: 1 beep and flash per second; Alarms latching with manual override or automatic reset; Additional diagnostic alarm and display message for low battery and pump stall

IP Rating

IP-65 unit running

Sampling Pump

Internal, integrated flow rate at 400 cc/mn

Sample from 100 (30m) horizontally or vertically

Wireless Range

Up to 15ft (5m) for BLE

EchoView Host: LOS > 660 ft (200 m)

ProRAE Guardian & RAEMesh Reader: LOS > 660 ft (200 m)

ProRAE Guardian & RAELink3 Mesh: LOS > 330 ft (100 m)

Safety Certifications

USA and Canada:: CSA, Classified as Intrinsically Safe for use in Class I, Division 1 Groups A, B, C, D
Europe: ATEX II 2G EEx ia IIC T4 IECEx CSA 10.0005 Ex ia IIC/IIB GbT4

Humidity

0% to 95% relative humidity (non-condensing)

Sensor Specifications

Gas Monitor	Range	Resolution	Response Time T90
VOCs	0 to 99.99 ppm 100 to 999.9 ppm 1000 to 9999 ppm	0.010 ppm 0.1 ppm 1 ppm	< 3 sec < 3 sec < 3 sec
Benzene	0-200 ppm	0.010 ppm	< 60 sec
Butadiene	0-200 ppm	0.010 ppm	< 60 sec

Resources

UltraRAE 3000 Datasheet

UltraRAE 3000 User-Guide

Media

UltraRae 3000 – Quick Guide to Benzene Measurements

UltraRAE 3000 User Guide

UltraRAE 3000 – How to Calibrate for Benzene Monitoring
