PM1703M
Pocket personal gamma detector/pager (Geiger-based) alerting the wearer to trace sources
- Woman-owned · HUB-certified
- Tax-exempt & POs accepted
- Calibration & repair
- Detector
- CsI(Tl) SiPM
- Battery lifetime
- 1000 h
- Ingress protection
- IP65
- Weight
- 200 g
- Dimensions
- 87 × 72 × 32 mm
Overview
The PM1703MA-II is a gamma-only Personal Radiation Detector (PRD) equipped with a high-sensitive CsI(Tl) SiPM scintillator for measurement of personal dose rate up to 300 µSv/h. It features ANSI N42.32-2016 and IEC 62401:2017 compliance, NORM-suppression algorithm for differentiating natural vs. man-made radiation, operation in extreme temperatures from –40 °C to 50 °C, long-life alkaline or rechargeable battery for 1000 hours, shockproof hermetic IP65 case, audible/visual/vibration alarms, and optional Bluetooth communication. Designed for customs, border control, HAZMAT teams, counter-terrorism, and first responders.
- ANSI N42.32-2016 and IEC 62401:2017 compliance
- NORM-suppression algorithm for differentiating color-coded alarms triggered by natural or man-made radiation materials
- Dedicated 0-9 scale mode with unitless dose rate indication allowing for ease of use and minimal training
- Operation in extreme temperatures from –40 °C to 50 °C
- Long-life alkaline or rechargeable battery for 1000 hours
- Shockproof hermetic case IP65
- Audible, visual, and vibration alarms
- Free Polismart® iOS and Android app for advanced operation
- USB and Bluetooth (PM1703MA-II BT) communication
Specifications
| Performance | |
| Detector | CsI(Tl) SiPM |
| Dose rate measurement range | 0.1 µSv/h to 300 µSv/h |
| Dose rate measurement accuracy | ± 30% |
| Energy range | 33 keV to 3.0 MeV (search) |
| Gamma radiation sensitivity | 100 cps per µSv/h (137Cs) 500 cps per µSv/h (241Am) |
| Response time | 0.25 s |
| Alarms | visual, audible, vibration |
| Atmospheric pressure | 84 to 106.7 kPa |
| Power | |
| Power supply | one AA alkaline or rechargeable battery |
| Battery lifetime | 1000 h |
| Physical | |
| Dimensions | 87 × 72 × 32 mm |
| Weight | 200 g |
| Connectivity | |
| Memory | 2000 events |
| Approvals & Warranty | |
| Ingress protection | IP65 |
| Other | |
| Smartphone communication | Bluetooth 4.0 |
| PC communication | USB |
| Drop test | 1.5 m |
| Operating temperature | –40 °C to 50 °C |
| Humidity | up to 98 % at +35 °C |
| Mean service lifetime | 8 years |
